HUAWEI LUNA2000-21-S1
SKU : HW-LN2000-21
The HUAWEI LUNA2000-21-S1 is a modular Lithium Iron Phosphate (LiFePO4) battery system designed for residential and small commercial solar energy storage applications. It can work seamlessly with Huawei inverters to create a comprehensive smart energy system.
Energy Capacity: 21.0 kWh
Product description
Datasheet
Performance
Communication
Standards Compliance (more available upon request)
Ordering and Deliverable Part
Available for order:
- Power module: LUNA2000-10KW-C1
- Number of power modules: 1
- Battery module: LUNA2000-7-E1
- Battery module energy: 6.9kWh
- Number of battery modules: 1 / 2 / 3
- Battery usable energy: 6.9kWh / 13.8kWh / 20.7kWh
- Max. charging & discharging power: 3.5kW / 7kW / 10.5kW
- Operating voltage range (single-phase system): 350560V
- Operating voltage range (three-phase system): 600980V
Communication
- Display: SOC status indicator, LED indicator
- Communication: RS485 / FE / CAN
Standards Compliance (more available upon request)
- Certificates: CE, RCM, CEC, VDE2510-50, IEC 62619, IEC 60730, UN38.3, ISO 13849, REACH, RoHS
Ordering and Deliverable Part
Available for order:
- LUNA2000-7-E1
- LUNA2000-10KW-C1
- Wall Mounting Bracket for LUNA2000-7/14/21-S1
